Stravifloor Mat

Hertsi Shopping Center (exterior)

Roll-Out System

Stravifloor Mat* products are low-profile roll-out isolation solutions made of regenerated materials, providing cost-effective structure-borne noise protection (including rolling noise). It can be used with gypsum, lightweight, or normal weight concrete without need for formwork, and can also be installed with plywood and cement board panelized systems.

Available in various thicknesses, Stravifloor Mat provides a great level of impact noise reduction with minimal system thickness and is a cost-effective solution to achieve building code requirements for floor-ceiling assemblies.

Stravifloor Mat line has flat underlayments (F) and wavy mats (W). The wavy form on the underside of the mat reduces the contact area to the subfloor and reduces the dynamic stiffness of the material to maximize its performance.

Main Characteristics

  • Natural frequency ≥ 15 Hz
  • Standard product height: 3 and 4.5 mm (flat) and 8 mm, 15 mm, 25 mm (wavy)
  • Minimum build-up height: 40 mm (timber/cement board) and 60 mm (concrete/screed)



*Previously known as CDM-MAT
  • Medium Performance

    Medium Performance

    Impact and rolling noise isolation consistently laboratory and field tested.

  • Roll-out System

    Roll-out System

    Full surface solution, without the need for formwork.

  • Cost-effective

    Cost-effective

    Solution made of of regenerated materials, providing cost-effective structure-borne noise protection.

  • Reduced Build-up Height

    Reduced Build-Up Height

    With minimal system thickness, it is the solution to achieve building code requirements for floor-ceiling assemblies.

  • Information Available to Download

Case Studies

  • Action Les Maourines (exterior)

    Action Les Maourines

    To limit the transmission of vibration and rolling noise generated by shopping carts and pallet stackers, a Stravifloor Mat-W15a was installed at Action.

  • Hertsi Shopping Center (exterior)

    Hertsi Shopping Center

    Stravifloor Mat and Stravifloor Channel systems reduce low-frequency noise from rolling pallet stackers and shopping carts in the Hertsi Shopping Center.

  • Monte da Virgem RTP (studio)

    Monte da Virgem RTP

    Stravifloor Mat and Stravifloor Jackup systems in combination with Stravilink decoupling strips, guarantee effective noise isolation at Monte da Virgem RTP.

  • Delhaize Kattendijkdok (exterior)

    Delhaize Kattendijkdok

    At Delhaize Kattendijkdok in Antwerp about 3000m² of floor have been decoupled using a resilient recycled rubber Stravifloor Mat solution with a wavy surface.

  • Sud Lisboa Restaurant (swimming pool)

    Sud Lisboa Restaurant

    At Sud Lisboa Restaurant a rooftop swimming pool was built over a Stravifloor Mat system specially designed for low frequency noise isolation.

  • The Address Residence Sky View (swimming pool)

    Address Residence Sky View

    A Stravifloor Mat solution prevents unwanted structure-borne noise and vibrations from reaching the residential apartments and hotel rooms within the towers.

  • Casas Rainha Dona Leonor (exterior)

    Casas Rainha Dona Leonor

    At Casas Rainha Dona Leonor special attention was paid to proper impact sound insulation of floating slabs in order to keep the noise pollution with limits.

  • Eiffel Art Studios (interior)

    Eiffel Art Studios

    Resilient Stravifloor Mat continuous mats, wall braces and machine isolation pads are installed in the most critical rooms of Eiffel Art Studios in Budapest.

  • Lux Prime at Benfica Stadium (exterior)

    Lux Prime at Benfica Stadium

    Lux Prime at Benfica Stadium condominium opted for a Stravifloor Mat acoustic isolation solution underneath the rooftop pool to cope with the vibrations.
